Vacuum Casting

Thermoplastic Polyurethane(Vacuum Casting-TPU)

130$

Vacuum Casting White
More Details

Excellent elasticity, good tensile strength and tear resistance. 30A–90A (The lower the value, the softer the material. Default is 70A. Please note in your order if a different softness is required.)

  • Mechanical Properties

    Hardness (Shore A): 0–100A

    Toughness: Good

    Shrinkage: 0.8–1.3%

    Specific Gravity: 1.2–1.4

  • Thermal Properties

    Heat Resistance: 70–80°C

    Low Temperature Resistance (Brittle Temperature): -10°C

    Molding Temperature: 140–180°C

  • Electrical Properties

    Dielectric Constant (60 Hz): 4.2

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±250 µm or ±0.25%


View Data Sheet

Vacuum Casting TPU(Transparent)(Vacuum Casting-TPU)

130$

Vacuum Casting Transparent
More Details

Excellent elasticity, good tensile strength and tear resistance, 30A–90A (The lower the value, the softer the material. Default is 70A. Please note in your order if a different softness is required.)

  • Thermal Properties
    Heat Resistance: 70–80°C
    Low-Temperature Resistance (Brittle Point): -10°C
    Molding Temperature: 140–180°C
    Shrinkage Rate: 0.8–1.3%

  • Mechanical Properties
    Shore Hardness: 0–100A
    Toughness: Good
    Specific Gravity: 1.2–1.4

  • Electrical Properties
    Dielectric Constant (60 Hz): 4.2

Max. Part Size:

900mm × 650mm × 600mm

Tolerance and Precision：

±250μm or ±0.25%


View Data Sheet

Vacuum Casting TPU(Colorful)(Vacuum Casting-TPU)

130$

Vacuum Casting Color options available
More Details

Excellent elasticity, good tensile strength and tear resistance, 30A–90A (The lower the value, the softer the material. Default is 60A. Please note in your order if a different softness is required.)

  • Thermal Properties
    Heat Resistance: 70–80℃
    Low Temperature Resistance: -10℃
    Molding Temperature: 140–180℃

  • Mechanical Properties
    Shore Hardness: 0–100A
    Toughness: Good
    Shrinkage: 0.8–1.3%
    Density: 1.2–1.4

  • Electrical Properties
    Dielectric Constant (60Hz): 4.2

Max. Part Size:

900mm × 650mm × 605mm

Tolerance and Precision：

±250μm or ±0.25%


View Data Sheet

Vacuum Casting TPU(Black)(Vacuum Casting-TPU)

130$

Vacuum Casting Black
More Details

Excellent elasticity, good tensile strength and tear resistance, This material is a lightweight thermoplastic blend similar to PP and PE, with relatively low surface hardness.

  • Thermal Properties
    Heat Resistance: 70–80℃
    Low Temperature Resistance: -10℃
    Molding Temperature: 140–180℃

  • Mechanical Properties
    Shore Hardness: 0–100A
    Toughness: Good
    Shrinkage: 0.8–1.3%
    Density: 1.2–1.4

  • Electrical Properties
    Dielectric Constant (60Hz): 4.2

Max. Part Size:

900mm × 650mm × 607mm

Tolerance and Precision：

±250μm or ±0.25%

View Data Sheet

Acrylonitrile Butadiene Styrene(Vacuum Casting-ABS)

138$

Vacuum Casting White Black
More Details

A low-viscosity, easy-to-use polyurethane resin with excellent mechanical properties, ideal for prototypes similar to ABS thermoplastics.

  • Mechanical Properties

    Tensile Strength: 50 MPa

    Flexural Strength: 75 MPa

    Flexural Modulus: 1800 MPa

    Impact Strength: 60 kJ/m²

    Shore Hardness (A): 78

    Linear Shrinkage: 2%

  • Thermal Properties

    Glass Transition Temperature: 85°C

  • Other Properties

    Maximum Casting Thickness: 10 mm

    Full Curing Time (23°C): 4 days

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet

Polyamide(Vacuum Casting-PA)

138$

Vacuum Casting White Black High stability
More Details

A transparent, easy-to-process, easy-to-demold, low-shrinkage polyurethane resin with mechanical properties similar to nylon.

  • Thermal Properties

    Heat Deflection Temperature (HDT @ 1.8 MPa): 65°C - 110°C

  • Mechanical Properties

    Tensile Strength (ISO527-1:2019): 60 MPa - 68 MPa

    Tensile Modulus (ISO527-1:2019): Not Provided

    Elongation at Break (ISO527-1:2018): 2% - 15%

    Bending Strength (GB/T 9341-2008): 80 MPa - 88 MPa

    Bending Modulus (GB/T 9341-2008): 2000 MPa - 3300 MPa

  • Impact Properties and Other Properties

    Impact Strength (GB/T 1843-2008): 7 kJ/m² - 14 kJ/m²

    Linear Shrinkage: 0.3% (mm/m)

    Hardness (Shore D): 84 - 87

    Maximum Pouring Thickness: 5 mm

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet

Polycarbonate(Vacuum Casting-PC)

138$

Vacuum Casting White Full-transparent&translucent Black
More Details

A transparent, easy-to-process, easy-to-demold, low-shrinkage polyurethane resin with mechanical properties similar to polycarbonate (PC)

  • Mechanical Properties

    Tensile Strength: 55 MPa

    Flexural Modulus: 1500 MPa

    Flexural Strength: 90 MPa

    Shore Hardness: 78

    Linear Shrinkage: 3 mm/m

    Elongation at Break: 16%

    Maximum Casting Thickness: 5 mm

    Full Curing Time (at 23°C): 4 days

  • Thermal Properties

    Heat Deflection Temperature: 50–60°C

  • Impact Properties

    Impact Strength: 50 kJ/m²

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet

Polypropylene(Vacuum Casting-PP)

138$

Vacuum Casting White Black
More Details

A vacuum casting material developed for producing PE and PP-like prototypes. It delivers a tactile feel and appearance similar to PE/PP parts.

  • Mechanical Properties

    Tensile Strength: 34 MPa

    Elongation at Break: 72%

    Flexural Strength: 39 MPa

    Flexural Modulus (Young's Modulus): 960 MPa

    Impact Strength: 10 kJ/m²

    Shore Hardness: 76

  • Thermal Properties

    Heat Deflection Temperature: 70°C

  • Dimensional Properties

    Linear Shrinkage: 3 mm/m

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet

Polyoxymethylene(Vacuum Casting-POM)

142$

Vacuum Casting Black White High strength&High rigidity
More Details

A transparent, easy-to-process, easy-to-demold, low-shrinkage polyurethane resin with mechanical properties similar to POM.

  • Thermal Properties

    Heat Deflection Temperature (HDT @ Load): 84°C - 100°C

  • Mechanical Properties

    Tensile Strength: 60 MPa - 73 MPa

    Linear Shrinkage: 0.3%

    Bending Modulus: 1790 MPa - 3400 MPa

    Bending Strength: 78 MPa - 92 MPa

    Impact Strength: 6 kJ/m² - 14 kJ/m²

    Hardness: 84 - 87 Type D

    Elongation at Break: 0.8% - 16%

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet

Polymethyl Methacrylate(Vacuum Casting-PMMA)

145$

Vacuum Casting Black- Translucent- White - Fully transparent Excellent surface finish
More Details

A transparent, easy-to-process, easy-to-demold, low-shrinkage polyurethane resin with mechanical properties similar to acrylic (PMMA).

  • Mechanical Properties

    Tensile Strength (ISO527-84): 55 MPa

    Flexural Modulus (ISO178-93): 1500 MPa

    Flexural Strength (ISO178-93): 90 MPa

    Elongation at Break (ISO37-77): 13%

    Hardness (ISO868-85): 78 Shore D

  • Thermal Properties

    Heat Deflection Temperature (T.M.A Meter): 50°C - 60°C

    Linear Shrinkage: 3 mm/m

    Maximum Casting Thickness: 5 mm

    Full Cure Time (at 23°C): 4 days

  • Impact Properties

    Impact Strength (ISO179/ID-94): 50 kJ/m²

Max. Part Size:

900mm x 650mm x 600mm

Tolerance and Precision：

±500 µm or ±0.5%


View Data Sheet
All Materials
